Quick Details
Size:
1220*2440mm, 1500*2000mm, 1800*2500mm
Place of Origin: Hunan, China
Brand Name: Huabond
Model Number: HTB-A623
Usage: Outdoor
Function:
Anti-Static, Antibacterial, Fireproof, Mould-Proof
Surface Treatment:
Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated
Delivery Time:
18-22 Days
Custom Brand:
Available
Production Line:
12 Production Lines
Fireproof:
B1 A2
Mildew-proof:
Yes
Printing:
Available
Aluminum Coil:
Self-Produced and Self-Used
Warranty:
20 Years Guaranteed Outdoor
Detailed
1.Compositions Of ACP
The upper and lower layers of aluminium, intermediate plastics, aluminium and plastics are compounded by high temperature polymer film.
The coating is covered with protective film.
2.Specification
Aluminum Skin Thickness:
0.50x0.50mm, 0.40x0.40mm,
0.30x0.30mm, 0.21x0.21mm, 0.15x0.15mm, 0.12mmx0.12mm,
0.10mmx0.10mm
Width:
1000mm ,1220mm (regular), 1250mm, 1300mm, 1500mm, 1550mm,
1570mm, 1575mm (Maximum);
Length:
2440mm (regular),
tailored by customers' offers;
6500mm(Maximum);
Standard size: 1220(Width) ×2440(Length)
Product Description
Product name | 3mm 4mm aluminum plastic composite panel |
Width | 1220mm,1250mm,1500mm,1570mm,2000mm |
Panel Thickness | 2mm 3mm 4mm 5mm 6mm |
Aluminum Thickness | 0.08mm to 0.50mm |
Length | 3200mm, 4000mm,5000mm (Max: 6 meter) |
Aluminum Alloy | AA1100,AA3003,AA5005(Other Grade On Requirement) |
Coating | PE/PVDF/NANO/Anti-scratch/Mill |
PE Core | Recycle PE Core/Fireproof PE Core/Unbreakable PE Core |
Application | 1) Exterior cladding; |
Features | 1) Good weather, pollutant and corrosion resistant |
| CoatingPE/PVDF/NANO/Anti-scratch/MillCoreRecycle PE Core/Fireproof PE Core/Unbreakable PE CoreColorSolid/Metallic/ Marble / Wood/Brush/GlossyStandard Size150*200MMCertificateISO9001, SGS, CE, ASTM. Brand Name: HUABOND Panel Thickness 2mm, 3mm, 4mm, 5mm, 6mm Aluminum Thickness: 0.06mm, 0.08mm, 0.12mm, 0.15mm, 0.18mm, 0.21mm, 0.25mm, 0.3mm, 0.45mm etc.Packing FCL: In bulk; LCL; In Wooden Package Delivery: 18 to 22 days after receiving deposit. |
Aluminum Composite Panel Exterior
1. Aluminum composite panel
Front side of ACP: aluminum roll coated with PVDF or PE
Core: nontoxic and low density polyethylene/plastic fireproof materials.
Rear side of ACP: aluminum coated with polyester
2. Series
Series | PE/PVDF Aluminum Composite Panel |
Marble Surface Aluminum Wall Cladding Panel | |
Wooden Aluminum Composite Panel | |
Mirror Aluminum Composite Panel | |
Brushed Aluminum Wall Cladding Panel |
3.Applications
-Exterior application as:
Wall cladding, facades, roofs and canopies, tunnels, column covers or renovations.
-Interior applications as:
Wall cladding, ceilings, bathroom, kitchens and balconies.
-Advertisement and market application as:
Display platforms, signboards, fascia and shop fronts etc.
>>FAQ
Q1.What is your MOQ, Delivery Time, Warranty, Payment, Production capacity?
A1:1. MOQ (Minimum Order Quantity): 600 m2 PE coating common colors; 1000 m2 PVDF coating and special colors.
2. Delivery Time: within 18 - 22 days after contract confirmed and deposit payment received.
3. Warranty: PVDF KY coating – 20 years for outside use; Polyester (PE) coating –5 years for outside use, 10 years for inside use.
4. Payment: 30% TT in advance, 70% see copy of BL.
5. Production Capacity: 37,507 m2 per day basic on 1220 * 2440mm 3mm thickness.
Q2.Do you have any test certificates?
A2: Yes, stable good quality is a key for long time business cooperation.
Factory has passed ISO9001: 2008 QUALITY SYSTEMS; ISO14001: 2004 ENVIRONMENTAL SYSTEMS; OHSAS18001: 2007 HEALTH SYSTEMS; our products have passed SGS, SGS-FR; A2 FR etc.
Q3.Where have your HUABOND aluminum composite panel been export?
A3: Our factory established in 1994; have already exported to USA, Canada, Mexico, Brazil, Chile, Panama, Europe Market, Australia, New Zealand, the Mid-east Countries, Southeast Asia and Africa.
Q4. What is delivery time?
18-20 days after deposit, except for public holidays.
Q5. How can you guarantee the quality?
We have rigorous quality test system, from raw materials to finished products, the materials must be checked and signed by QC .
Q6. How long can I get a quote?
The quotation can be provided not long than 24 hours on condition that we know all detailed requirements.
Q7. Can I get a sample?
Yes we offer free samples. Delivery cost is to be paid by clients.
Q8. Can you provide OEM service?
A4: Yes, OEM accepted. Just give us your logo, we will send some protective film design for your choice. And 300 USD should be paid for the first order, which will be returned back in the 5th containers order.
Q9. What's the available panel size and thickness?
A5: 1. Width: 1000-1575mm; 1220mm, 1250mm, 1500mm 2000mm are recommended.
2. Length: accept customized length, recommend 2440mm, 3050mm, 4050mm, 5000mm.
3. Panel Thickness: 2mm-16mm; recommend 3,4mm.
4. Aluminum thickness:0.10-0.5mm, such as 0.21mm, 0.30mm, 0.40mm, 0.50mm.
Q10. What is the minimum order quantity?
600 square meters for aluminum composite panel.
Q11.Can I buy installation accessories from you?
Yes, we provide all installation accessories.
