Quick Details
Place of Origin: Hunan, China
Brand Name: HUABOND®
Model Number: H-H104
Usage: Outdoor
Core cell: 4.8-30mm
Material: Aluminum
Color: Yellow, red, black, etc.
Size: Customer's Requirements
Function: Anti-Static, Antibacterial, Fireproof, Mould Proof
Surface Treatment: Anodized, Brushed, Foil Decoration, Mirror
Application: Furniture\Doors\Decoration materials.
Supply Ability: 15000 Square Meter/per Month
Packaging Details: Customer's Requirements
Port: Shenzhen or Guangzhou port
|
Information: |
|
Product name |
Aluminum Honeycomb Panel |
|
Thickness |
6-100mm, other size can be customized. |
|
Max size |
1600*6000mm (Flat) |
|
Aluminum alloy |
1100/3003/3105 |
|
Surface treatment |
PE/PVDF coating |
|
Painting |
PPG, Akzo Nobel, Becker, etc. |
|
Color |
Solid color, Metallic Color, Wooden Color, Stone Color, etc. |
|
Size/Design |
Sizes and design are available according your detail drawings |
|
Certificates: |
SGS, ISO 9001:2000, CE, KYNAR 500, etc. |
|
MOQ: |
600 sqm |
|
Delivery time: |
around 22-25 days, depends on the panel drawings and quantity |
|
Payment Term: |
TT, LC at sight |
|
Production Capability: |
30000Sqm Per Month |
|
More Service: |
OEM, Small samples free |
|
Main Production: |
Stone Aluminum Single Panel, Stone colored Aluminum Single Panel, Wooden colored Aluminum Single Panel, etc. |
|
Alloy Honeycomb |
Compression |
Plate Shear |
|||
|
Designation |
Bare |
L Direction |
W Direction |
||
|
Material Cell Size |
Strength psi |
Strength psi |
Modulus ksi |
Strength psi |
Modulus ksi |
|
mm --- inch |
Typ. |
Typ. |
Typ. |
Typ. |
Typ. |
|
6.4---1/4 |
625 |
365 |
70 |
215 |
38 |
|
9.5---3/8 |
340 |
230 |
45 |
130 |
22 |
|
12.7--1/2 |
190 |
140 |
28 |
80 |
14 |
|
17-----3/4 |
120 |
100 |
20 |
65 |
11 |
|
25.4----1 |
80 |
65 |
14 |
45 |
7 |
|
9.5-----3/8 |
362 |
250 |
55 |
160 |
26 |
|
Sizes are available on requested, above values are not guaranteed and should be used as indication only. |
|||||
Advantage:
1. Design ability;
2. Sample order is acceptable
3. High performance cost ratio;
4. Fast delivery time and fast resolve problem attitude.
5. Good experience and cooperation with big clients in the world;
FAQ
What information should I let you know?
1) The size of products (Alloy ,width ,thickness, color, application);
2) The specification of the products you want;
3) It will be better if you can show us the pictures or design sketch. Samples will be best for clarifying. If not, we will recommend relevant products with details for reference.
2. Do you have any certificates?
Our products passed inspection of SGS, ISO9001, CTC.
Quality is our culture! Every worker keeps the QC from beginning to end, Quality control department especially responsible for quality checking in each process.
3.How can I get some samples?
We are honored to offer you samples. New clients are expected to pay for the courier cost. The samples are free for you, this charge will be deducted from the payment for
